Water Level Control Panel

This water-level control panel uses a wired tank float to control a 24 V solenoid valve on pressurised water pipework, helping automate tank filling.

Listed configuration

• Mains supply: 240 V AC
• Control output: for a 24 V solenoid valve
• Level input: wired float
• Enclosure dimensions: 240 × 190 × 90 mm

Selection and installation

Confirm that the float, solenoid valve and their electrical ratings match the panel before ordering. Installation and mains wiring must be completed by a suitably qualified person, with the supply isolated before work begins.

The listing does not state an enclosure IP rating, circuit current rating or included accessories; verify these where the installation depends on them.
